W9412G6JH
10.3 Capacitance
(V DD = V DDQ = 2.5V ± 0.2V, f = 1 MHz, T A = 25°C, V OUT (DC) = V DDQ /2, V OUT (Peak to Peak) = 0.2V)
SYMBOL
C IN
C CLK
C I/O
PARAMETER
Input Capacitance (except for CLK pins)
Input Capacitance (CLK pins)
DQ, DQS, DM Capacitance
MIN.
2.0
3.0
1.5
MAX.
4.0
5.0
5.5
DELTA
(MAX.)
0.5
0.25
0.5
UNIT
pF
pF
pF
Notes: These parameters are periodically sampled and not 100% tested.
10.4 Leakage and Output Buffer Characteristics
SYMBOL
PARAMETER
MIN.
MAX.
UNIT
NOTES
Input Leakage Current
I I (L)
Any input 0V ≤ V IN ≤ V DD , V REF Pin 0V ≤ V IN ≤ 1.35V
-2
2
μA
(All other pins not under test = 0V)
I O (L)
V OH
V OL
Output Leakage Current
(Output disabled, 0V ≤ V OUT ≤ V DDQ )
Output High Voltage
(under AC test load condition)
Output Low Voltage
(under AC test load condition)
-5
V TT +0.76
-
5
-
V TT -0.76
μA
V
V
Output Levels: Full drive option
I OH
High Current
-15
-
mA
4, 6
(V OUT = V DDQ - 0.373V, min. V REF , min. V TT
I OL
Low Current
(V OUT = 0.373V, max. V REF , max. V TT )
15
-
mA
4, 6
Output Levels: Reduced drive option - 60%
I OHR
High Current
-9
-
mA
5
(V OUT = V DDQ - 0.763V, min. V REF , min. V TT
I OLR
Low Current
(V OUT = 0.763V, max. VREF, max. V TT )
9
-
mA
5
Output Levels: Reduced drive option - 30%
I OHR (30)
High Current
-4.5
-
mA
5
(V OUT = V DDQ – 1.056V, min. V REF , min. V TT
I OLR (30)
Low Current
(V OUT = 1.056V, max. V REF , max. V TT )
4.5
-
mA
5
Publication Release Date: Jan. 14, 2014
- 24 -
Revision: A04
